Well suited for live sound, home recording, and content creators, the Mackie ProFX6v3+ is a 6-channel professional analog mixer with powerful enhancements for studio-quality recordings and live streams. Capture your performance with Onyx preamps and channel EQ, add computer audio via loopback, bring in calls via Bluetooth, and enhance your sound with upgraded GigFX+ effects on a color LCD screen.
Channels 1 & 2 features Onyx microphone preamps with 60 dB of headroom, a 2-band EQ, Hi-Z selection for instruments, a low-cut filter, and 1-button compression that's designed to sound great on any signal. Edit FX parameters on a full-color screen. The three recording modes (Standard Stereo, Channel 1&2 Direct, and Loopback) provide a ton of flexibility when live streaming or recording directly to a computer. The ProFX6v3+ includes a USB cable and Waveform OEM recording software.
Key Specs
| Number of Analog Input Channels |
6
|
| Number of Mic Preamps |
2
|
| Analog Output Channels |
2x Stereo Master Output
1x Stereo Headphone Output
|
| Mix Routing |
Stereo Main Mix
|
| Built-In Effects |
12x Preset (Factory)
|
| USB I/O |
1x USB-B 2.0 (2-Track Record, Audio Streaming, Host Connection)
|
| Wireless |
Bluetooth
*Built-In
|
| Rack Mountable |
No
|
Mixer
| Number of Analog Input Channels |
6
|
| Number of Mic Preamps |
2
|
| Analog Output Channels |
2x Stereo Master Output
1x Stereo Headphone Output
|
| Mix Routing |
Stereo Main Mix
|
| Faders & Level Adjustment |
No
|
| Meters |
Main Meter:
2x 8-Segment LED
|
| Meter Range |
Main Meter:
-24 dB to +14 dB Plus Peak/Clip
|
Signal Processing
| Gain/Trim Range |
-20 dB to +40 dB
|
| EQ Parameters |
Low: ±15 dB at 80 Hz
High: ±15 dB at 12 kHz
|
| Filters |
High-Pass: 100 Hz, 18 dB/Octave
|
| Built-In Effects |
12x Preset (Factory)
|
Digital Audio
| Sample Rates |
Up to 192 kHz
|
| Bit Depth |
24-Bit
|
| DSP |
No
|
Performance
| Frequency Response |
Mic Input to Output:
20 Hz to 30 kHz +0/-1 dB (Unity Gain)
|
| Max Input Level |
+22 dB
|
| Output Level |
Main Output:
+28 dBu at Max Gain
All Other Output:
+22 dBu at Max Gain
|
| I/O Impedance |
Mic Input:
3.8 Kilohms
Insert Return:
10 Kilohms
Line Input:
≥ 20 Kilohms
Headphone Output:
25 Ohms
Main Output:
120 Ohms (Unbalanced)
240 Ohms (Balanced)
|
| Crosstalk |
Adjacent Inputs:
-90 dB at 1 kHz
Input to Output:
-80 dB at 1 kHz
Fader Off:
-75 dB at 1 kHz
Muted:
-90 dB at 1 kHz
|
| CMRR |
70 dB at Max Gain (1 kHz, Mic In to Main Out)
|
| EIN |
-126 dBu at Max Gain (150-Ohm Input)
|
| Noise Floor |
All Outputs:
-95 dBu (Master Level at -∞, Channel Levels at -∞)
-80 dBu (Master Level at Unity, One Channel Level at Unity)
|
| THD+N |
Mic Input to Main Output:
< 0.03% (+4 dBu)
|
Connectivity
| Analog Inputs |
2x Combo XLR-1/4" 3-Pin Balanced/Unbalanced Mic/Line/Hi-Z Input
2x 1/4" TRS Balanced/Unbalanced Line Input (1 Stereo Pair)
1x 1/8" / 3.5 mm TRS Unbalanced Stereo Line Input
|
| Analog Outputs |
2x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Main Output (1 Stereo Pair)
1x 1/4" TRS Unbalanced Stereo Headphone Output
|
| Phantom Power |
+48 V, Selectable On/Off (Applied to All Inputs)
|
| USB I/O |
1x USB-B 2.0 (2-Track Record, Audio Streaming, Host Connection)
|
| USB I/O Capacity |
2x Input / 4x Output
|
| Wireless |
Bluetooth
*Built-In
|
| Mobile App Compatible |
No
|
Power
| AC Input Power |
Universal:
100 to 240 VAC, 50 / 60 Hz
|
| Power Supply Output |
12 VDC at 2 A
|
Physical
| Rack Mountable |
No
|
| Dimensions |
7.5 x 8.4 x 2.9" / 190 x 213 x 74 mm
|
| Weight |
2.6 lb / 1.2 kg
|
Packaging Info
| Package Weight |
3.745 lb
|
| Box Dimensions (LxWxH) |
12.1 x 9.5 x 4.1"
|
What's in the Box:
- Mackie ProFX6v3+ 6-Channel Analog Mixer with Built-In FX, USB Recording, and Bluetooth
- USB-C Cable
- Power Supply
- Waveform OEM Download
-
Limited 1-Year Manufacturer Warranty
