Mackie Onyx12 12-Channel Premium Analog Mixer with Multitrack USB

Product image 1
1 / 4

Mackie Onyx12 12-Channel Premium Analog Mixer with Multitrack USB

Key Features
  • Onyx Preamps
  • British-Style Perkins 3-Band EQ
  • Premium Analog Circuitry
  • Ultralow-Noise Design
  • Record & Playback to/from Mac/PC via USB
  • Studio Command Full-Color Display
  • Robust Digital Effects Engine
  • Dedicated Control Room Output
  • 12-Segment Stereo Meters
  • Includes Powerful Software and Plug-Ins



Overview

Musicians, artists, engineers, and broadcast studios looking for a professional-quality compact mixing solution for live audio, home recording, and content creation should look no further than the Mackie Onyx12, a 12-channel mixer with 24-bit / 96 kHz 14x4 multitrack recording and high-gain Onyx preamps.

The Onyx12 is packed with features including British-style Perkins EQ, powerful DSP effects, a full-color display, and integrated stereo recording and playback from an SD card. The mixer provides an end-to-end ultralow-noise design, which delivers the sound quality professionals demand.

Key Specs

Number of Analog Input Channels
14 (8 Mono / 5 Stereo)
Number of Mic Preamps
8
Analog Output Channels
2x Stereo Master Output
2x Stereo Control Room/Monitor Output
2x Mono Aux Send Output
1x Mono FX Send Output
1x Stereo Headphone Output
Mix Routing
1x Stereo Main Mix per Mono Input Channel, Stereo Input Channel, Aux Bus/Subgroup
EQ
3-Band Semi-Parametric (Mono Channels)
3-Band Shelving/Notch/Peak
Built-In Effects
Yes
USB I/O
1x USB-B (Audio Playback, Host Connection, Recording)
Max Multitrack Recording
14 Tracks
Rack Mountable
No

Mixer
Number of Analog Input Channels
14 (8 Mono / 5 Stereo)
Number of Mic Preamps
8
Analog Output Channels
2x Stereo Master Output
2x Stereo Control Room/Monitor Output
2x Mono Aux Send Output
1x Mono FX Send Output
1x Stereo Headphone Output
Mix Routing
1x Stereo Main Mix per Mono Input Channel, Stereo Input Channel, Aux Bus/Subgroup
Faders & Level Adjustment
9x 2.4" / 60 mm Channel Fader
1x 2.4" / 60 mm FX Fader
2x 2.4" / 60 mm Bus/Subgroup Fader
1x 2.4" / 60 mm Master Fader
Meters
Main Meter:
2x 12-Segment LED
Meter Range
-30 dB to +20 dB Peak/Clip
Input Pad
No
Input Polarity
No
Dynamic Processing
No
Sidechain Filters
No
EQ
3-Band Semi-Parametric (Mono Channels)
3-Band Shelving/Notch/Peak
EQ Parameters
Mono Channels:
High: ±15 dB at 12 kHz
Mid: ±15 dB at 100 Hz to 8 kHz
Low: ±15 dB at 80 Hz
Stereo Channels:
High: ±15 dB at 12 kHz
Mid: ±15 dB at 2.5 kHz
Low: ±15 dB at 80 Hz
Graphic EQ
No
Filters
Input Channels:
1x High-Pass: 100 Hz
Solo/Mute
Solo per Input Channel
Mute per Input Channel, Bus, FX Bus, Master
Built-In Effects
Yes

Digital Audio
Sample Rates
96 kHz
Bit Depth
24-Bit

Connectivity
Analog Inputs
8x XLR 3-Pin Balanced Mic Input
4x 1/4" TRS Balanced/Unbalanced Line Input
4x 1/4" TRS Unbalanced Line Insert
2x 1/4" TRS Balanced/Unbalanced Hi-Z Input
10x 1/4" TRS Balanced/Unbalanced Stereo Line Input (4 Stereo Pairs)
1x 1/4" TRS Footswitch Input
Analog Outputs
2x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Stereo Main Output (1 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Stereo Monitor Output (1 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Mono Aux/Monitor Output
1x 1/4" TRS Balanced/Unbalanced FX Send
Phantom Power
+48 V (Applied to All Inputs)
Digital I/O
No
MIDI I/O
No
USB I/O
1x USB-B (Audio Playback, Host Connection, Recording)

Recording
Max Multitrack Recording
14 Tracks
Media Support
SD

Power
AC Input Power
100 to 240 VAC, 50 / 60 Hz
AC Power I/O
1x IEC Input
Power Consumption
40 W

Physical
Rack Mountable
No
Dimensions
14 x 14.8 x 4.5" / 355.6 x 375.9 x 114.3 mm
Weight
12.7 lb / 5.8 kg

Packaging Info
Package Weight
17.26 lb
Box Dimensions (LxWxH)
20 x 19 x 9.5"

What's in the Box:

  • Mackie Onyx12 12-Channel Premium Analog Mixer with Multitrack USB
  • Power Cord
  • Limited 1-Year Manufacturer Warranty
Key Features
  • Onyx Preamps
  • British-Style Perkins 3-Band EQ
  • Premium Analog Circuitry
  • Ultralow-Noise Design
  • Record & Playback to/from Mac/PC via USB
  • Studio Command Full-Color Display
  • Robust Digital Effects Engine
  • Dedicated Control Room Output
  • 12-Segment Stereo Meters
  • Includes Powerful Software and Plug-Ins



Overview

Musicians, artists, engineers, and broadcast studios looking for a professional-quality compact mixing solution for live audio, home recording, and content creation should look no further than the Mackie Onyx12, a 12-channel mixer with 24-bit / 96 kHz 14x4 multitrack recording and high-gain Onyx preamps.

The Onyx12 is packed with features including British-style Perkins EQ, powerful DSP effects, a full-color display, and integrated stereo recording and playback from an SD card. The mixer provides an end-to-end ultralow-noise design, which delivers the sound quality professionals demand.

Key Specs

Number of Analog Input Channels
14 (8 Mono / 5 Stereo)
Number of Mic Preamps
8
Analog Output Channels
2x Stereo Master Output
2x Stereo Control Room/Monitor Output
2x Mono Aux Send Output
1x Mono FX Send Output
1x Stereo Headphone Output
Mix Routing
1x Stereo Main Mix per Mono Input Channel, Stereo Input Channel, Aux Bus/Subgroup
EQ
3-Band Semi-Parametric (Mono Channels)
3-Band Shelving/Notch/Peak
Built-In Effects
Yes
USB I/O
1x USB-B (Audio Playback, Host Connection, Recording)
Max Multitrack Recording
14 Tracks
Rack Mountable
No

Mixer
Number of Analog Input Channels
14 (8 Mono / 5 Stereo)
Number of Mic Preamps
8
Analog Output Channels
2x Stereo Master Output
2x Stereo Control Room/Monitor Output
2x Mono Aux Send Output
1x Mono FX Send Output
1x Stereo Headphone Output
Mix Routing
1x Stereo Main Mix per Mono Input Channel, Stereo Input Channel, Aux Bus/Subgroup
Faders & Level Adjustment
9x 2.4" / 60 mm Channel Fader
1x 2.4" / 60 mm FX Fader
2x 2.4" / 60 mm Bus/Subgroup Fader
1x 2.4" / 60 mm Master Fader
Meters
Main Meter:
2x 12-Segment LED
Meter Range
-30 dB to +20 dB Peak/Clip
Input Pad
No
Input Polarity
No
Dynamic Processing
No
Sidechain Filters
No
EQ
3-Band Semi-Parametric (Mono Channels)
3-Band Shelving/Notch/Peak
EQ Parameters
Mono Channels:
High: ±15 dB at 12 kHz
Mid: ±15 dB at 100 Hz to 8 kHz
Low: ±15 dB at 80 Hz
Stereo Channels:
High: ±15 dB at 12 kHz
Mid: ±15 dB at 2.5 kHz
Low: ±15 dB at 80 Hz
Graphic EQ
No
Filters
Input Channels:
1x High-Pass: 100 Hz
Solo/Mute
Solo per Input Channel
Mute per Input Channel, Bus, FX Bus, Master
Built-In Effects
Yes

Digital Audio
Sample Rates
96 kHz
Bit Depth
24-Bit

Connectivity
Analog Inputs
8x XLR 3-Pin Balanced Mic Input
4x 1/4" TRS Balanced/Unbalanced Line Input
4x 1/4" TRS Unbalanced Line Insert
2x 1/4" TRS Balanced/Unbalanced Hi-Z Input
10x 1/4" TRS Balanced/Unbalanced Stereo Line Input (4 Stereo Pairs)
1x 1/4" TRS Footswitch Input
Analog Outputs
2x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Stereo Main Output (1 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Stereo Monitor Output (1 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Mono Aux/Monitor Output
1x 1/4" TRS Balanced/Unbalanced FX Send
Phantom Power
+48 V (Applied to All Inputs)
Digital I/O
No
MIDI I/O
No
USB I/O
1x USB-B (Audio Playback, Host Connection, Recording)

Recording
Max Multitrack Recording
14 Tracks
Media Support
SD

Power
AC Input Power
100 to 240 VAC, 50 / 60 Hz
AC Power I/O
1x IEC Input
Power Consumption
40 W

Physical
Rack Mountable
No
Dimensions
14 x 14.8 x 4.5" / 355.6 x 375.9 x 114.3 mm
Weight
12.7 lb / 5.8 kg

Packaging Info
Package Weight
17.26 lb
Box Dimensions (LxWxH)
20 x 19 x 9.5"

What's in the Box:

  • Mackie Onyx12 12-Channel Premium Analog Mixer with Multitrack USB
  • Power Cord
  • Limited 1-Year Manufacturer Warranty
