PreSonus Revelator io24 Desktop 2x4 USB Type-C Audio/MIDI Interface
1 / 6
+1
PreSonus Revelator io24 Desktop 2x4 USB Type-C Audio/MIDI Interface
Key Features
Podcasters, Streamers, and Musicians
USB Type-C Connectivity
2 XMAX-L Mic/Line/Instrument Preamps
1 Headphone Output, 2 Monitor Outs
24-Bit / 96 kHz AD/DA
Bus Powered / Mac, Windows
Phantom Power, Direct Monitor, MIDI I/O
Onboard DSP with Versatile Presets
2 Dedicated Loopback Channels
DAWs, VIs, Plug-Ins, Loops, and Samples
Overview
Loaded with onboard DSP, loopback channels, and complete configuration for streaming at the click of a button, the PreSonus Revelator io24 desktop 2x4 USB Type-C audio/MIDI interface blends studio-quality sonic performance and refreshing ease of use, so podcasters, live streamers, content creators, and musicians can get great sounds in a hurry. Plus, it comes with a powerful software package that includes two DAWs, a slew of virtual instruments, plug-in effects, loops, samples, and much more.
On the hardware side, the two XMAX-L preamps and 24-bit / 96 kHz converters deliver clarity and natural tonality for mics, instruments, or line-level sources. Whether you use the factory presets or create your own, the built-in Fat Channel processing offers pro-level impact without ever taxing your computer. Use the two loopback channels and integrated mixer to pipe in backing tracks or a call-in guest, and feed independent mixes to the main and headphone outputs. There's even a 5-pin MIDI I/O to allow simple hookup of a MIDI controller, synthesizer, or groovebox, making the Revelator io24 advantageous for beatmakers, keyboardists, and electronic music producers as well.
48 V, Selectable On/Off (Selectable on Individual Inputs)
Digital Audio I/O
No
Host Connection
1x USB-C
Host Connection Protocol
USB 2.0
USB (Non-Host)
No
Sync I/O
No
Network I/O
No
MIDI I/O
1x DIN 5-Pin Input 1x DIN 5-Pin Output
Expansion Slots
No
Performance
Frequency Response
Mic, Hi-Z Inputs: 20 Hz to 20 kHz +0.1/-0.3 dB (Unity Gain) Monitor Outputs: 20 Hz to 20 kHz +0.1/-0.3 dB (Unity Gain) Headphone Outputs: 20 Hz to 20 kHz +0.1/-0.5 dB
Maximum Input Level
Mic/Hi-Z Inputs: +10 dBu (Min Gain)
Maximum Output Level
Monitor Outputs: +10 dBu (Balanced, 1 kHz)
Headphone Output Power
40 mW per Channel into 56 Ohms (Max)
Impedance
Mic Inputs: 1.4 Kilohms (Balanced) Hi-Z Inputs: 1 Megohm Headphone Outputs: 32 to 300 Ohms
Dynamic Range
AD/DA Converters: 105 dB
THD+N
Mic Inputs: 0.009% (1 kHz, Min Gain, at -1 dBFS) Monitor Outputs: 0.003% (1 kHz, Unity Gain, at -1 dBFS) Headphone Outputs: 0.01% (1 kHz, at 0 dBFS)
EIN
Mic Inputs: -126 dBu A-Weighted (150-Ohm Source, Max Gain)
Digital Audio
Sample Rates
44.1 / 48 / 88.2 / 96 kHz
Sample Rate Conversion
No
Bit Depths
24-Bit
Latency
Zero-Latency Direct Monitoring
Sync Sources
Internal
Audio Storage & Playback
Media/Memory Card Slot
No
Compatibility
OS Compatibility
Computer: macOS 10.13 or Later / Windows 10 or Later Mobile: Android/iPadOS
OS Compatibility
macOS 10.13 or Later (64-Bit Only) Windows 10 (64-Bit Only) 9.0.3 or Later
Processor Requirement
Mac: Intel Core i3 or Better PC: Intel Core i3 or Better AMD A10 or Better
RAM Requirements
4 GB, 8 GB Recommended
Storage Requirements
30 GB
Mobile Device Compatibility
iPad Pro (with USB-C) iPad Air (with USB-C) iPad Mini with Retina (with USB-C) iPad 4th Gen. (with USB-C) Android Smartphone (with USB-C) Android Tablet (with USB-C)
Required Hardware
Available USB 2.0 Port or USB-C Port USB Cable (Included)
Power
Power Requirements
USB Bus Power
Physical
Dimensions
6.25 x 6.25 x 2.5" / 15.88 x 15.88 x 6.3 cm
Weight
2.0 lb / 0.9 kg
Packaging Info
Package Weight
2.41 lb
Box Dimensions (LxWxH)
8.5 x 8.4 x 5.2"
What's in the Box:
PreSonus Revelator io24 Desktop 2x4 USB Type-C Audio/MIDI Interface
USB Type-C to USB Type-A Cable
Limited 1-Year Manufacturer Warranty
Key Features
Podcasters, Streamers, and Musicians
USB Type-C Connectivity
2 XMAX-L Mic/Line/Instrument Preamps
1 Headphone Output, 2 Monitor Outs
24-Bit / 96 kHz AD/DA
Bus Powered / Mac, Windows
Phantom Power, Direct Monitor, MIDI I/O
Onboard DSP with Versatile Presets
2 Dedicated Loopback Channels
DAWs, VIs, Plug-Ins, Loops, and Samples
Overview
Loaded with onboard DSP, loopback channels, and complete configuration for streaming at the click of a button, the PreSonus Revelator io24 desktop 2x4 USB Type-C audio/MIDI interface blends studio-quality sonic performance and refreshing ease of use, so podcasters, live streamers, content creators, and musicians can get great sounds in a hurry. Plus, it comes with a powerful software package that includes two DAWs, a slew of virtual instruments, plug-in effects, loops, samples, and much more.
On the hardware side, the two XMAX-L preamps and 24-bit / 96 kHz converters deliver clarity and natural tonality for mics, instruments, or line-level sources. Whether you use the factory presets or create your own, the built-in Fat Channel processing offers pro-level impact without ever taxing your computer. Use the two loopback channels and integrated mixer to pipe in backing tracks or a call-in guest, and feed independent mixes to the main and headphone outputs. There's even a 5-pin MIDI I/O to allow simple hookup of a MIDI controller, synthesizer, or groovebox, making the Revelator io24 advantageous for beatmakers, keyboardists, and electronic music producers as well.
48 V, Selectable On/Off (Selectable on Individual Inputs)
Digital Audio I/O
No
Host Connection
1x USB-C
Host Connection Protocol
USB 2.0
USB (Non-Host)
No
Sync I/O
No
Network I/O
No
MIDI I/O
1x DIN 5-Pin Input 1x DIN 5-Pin Output
Expansion Slots
No
Performance
Frequency Response
Mic, Hi-Z Inputs: 20 Hz to 20 kHz +0.1/-0.3 dB (Unity Gain) Monitor Outputs: 20 Hz to 20 kHz +0.1/-0.3 dB (Unity Gain) Headphone Outputs: 20 Hz to 20 kHz +0.1/-0.5 dB
Maximum Input Level
Mic/Hi-Z Inputs: +10 dBu (Min Gain)
Maximum Output Level
Monitor Outputs: +10 dBu (Balanced, 1 kHz)
Headphone Output Power
40 mW per Channel into 56 Ohms (Max)
Impedance
Mic Inputs: 1.4 Kilohms (Balanced) Hi-Z Inputs: 1 Megohm Headphone Outputs: 32 to 300 Ohms
Dynamic Range
AD/DA Converters: 105 dB
THD+N
Mic Inputs: 0.009% (1 kHz, Min Gain, at -1 dBFS) Monitor Outputs: 0.003% (1 kHz, Unity Gain, at -1 dBFS) Headphone Outputs: 0.01% (1 kHz, at 0 dBFS)
EIN
Mic Inputs: -126 dBu A-Weighted (150-Ohm Source, Max Gain)
Digital Audio
Sample Rates
44.1 / 48 / 88.2 / 96 kHz
Sample Rate Conversion
No
Bit Depths
24-Bit
Latency
Zero-Latency Direct Monitoring
Sync Sources
Internal
Audio Storage & Playback
Media/Memory Card Slot
No
Compatibility
OS Compatibility
Computer: macOS 10.13 or Later / Windows 10 or Later Mobile: Android/iPadOS
OS Compatibility
macOS 10.13 or Later (64-Bit Only) Windows 10 (64-Bit Only) 9.0.3 or Later
Processor Requirement
Mac: Intel Core i3 or Better PC: Intel Core i3 or Better AMD A10 or Better
RAM Requirements
4 GB, 8 GB Recommended
Storage Requirements
30 GB
Mobile Device Compatibility
iPad Pro (with USB-C) iPad Air (with USB-C) iPad Mini with Retina (with USB-C) iPad 4th Gen. (with USB-C) Android Smartphone (with USB-C) Android Tablet (with USB-C)
Required Hardware
Available USB 2.0 Port or USB-C Port USB Cable (Included)
Power
Power Requirements
USB Bus Power
Physical
Dimensions
6.25 x 6.25 x 2.5" / 15.88 x 15.88 x 6.3 cm
Weight
2.0 lb / 0.9 kg
Packaging Info
Package Weight
2.41 lb
Box Dimensions (LxWxH)
8.5 x 8.4 x 5.2"
What's in the Box:
PreSonus Revelator io24 Desktop 2x4 USB Type-C Audio/MIDI Interface
USB Type-C to USB Type-A Cable
Limited 1-Year Manufacturer Warranty
$65.66
Original: $187.61
-65%
PreSonus Revelator io24 Desktop 2x4 USB Type-C Audio/MIDI Interface—
$187.61
$65.66
