BirdDog KBD PTZ Controller with Integrated Screen

Product image 1
1 / 3

BirdDog KBD PTZ Controller with Integrated Screen

Key Features

  • PTZ Controller with 1280 x 720 Display
  • Monitor up to 4 Cameras Simultaneously
  • Effortless Camera Settings Sync
  • NDI|HX2 & NDI|HX3 Support
  • Integrated Tally Borders
  • Streamlined Access
  • Ocean-Bound Plastics & Aluminum Build



Overview

Control your PTZ multicamera setup and monitor up to four cameras simultaneously with the BirdDog KBD PTZ Controller with Integrated Screen. Built with ocean-bound plastics and recyclable aircraft-grade aluminum, the KDP boasts a rugged, ergonomic design with a large 1280 x 720 display to allow you to quickly pair and switch cameras with a single keystroke.

The new Effortless Camera Settings Sync function enables you to easily copy settings from one X-series device to another, and the integrated tally borders facilitate live switching with optional TriCaster or vMix platforms. The KDP offers NDI|HX2 and NDI|HX3 support as well as VISCA-IP, ONVIF, RS-232, and RS-422 for smooth workflow versatility. Balancing power, operational comfort, and eco-friendly innovation, the KDP is the ideal companion for studio production, live events, and mobile program acquisition applications.


Key Specs

General
Number of Supported Cameras
255 Channels via IP
Supported Control Protocols
IP
NDI
NDI|HX2
NDI|HX3
ONVIF
Pelco-D
Pelco-P
RS-232
RS-422
VISCA
IP Streaming
NDIHX, ONVIF: UHD 4K
Control I/O
1x D-Sub 9-Pin (RS-232) Input/Output
1x Phoenix (RS-422) Input/Output
1x RJ45 (IP Control, LAN) Input/Output
Other I/O
1x USB-A Input/Output
Controls
1x 3-Axis, Pan/Tilt, Programmable, Multifunction, Auto-Focus, Manual-Focus, Camera Movement Speed, Focus Speed, White Balance Joystick
Focus, Auto-Focus, Manual-Focus, Gain, Camera Selection, Preset Selection, Menu Buttons
Presets
255 via IP, RS-232, VISCA, Pelco-P, Pelco-D
Display
Native Resolution
1280 x 720
Touchscreen
No
Power
PoE Support
PoE 802.3af
Power Connectors
1x Barrel / Coaxial
Power Consumption
≤5 W
Input Power
12 VDC
Physical
Operating Conditions
14 to 130°F / -10 to 54°C at 20 to 80% Humidity
Storage Conditions
14 to 130°F / -10 to 54°C at 0 to 90% Humidity
Security Lock Support
No
Dimensions
14.8 x 7 x 4.6" / 377 x 177 x 118 mm

What is in the Box:

  • BirdDog KBD PTZ Controller with Integrated Screen
  • Limited 1-Year Manufacturer Warranty

Key Features

  • PTZ Controller with 1280 x 720 Display
  • Monitor up to 4 Cameras Simultaneously
  • Effortless Camera Settings Sync
  • NDI|HX2 & NDI|HX3 Support
  • Integrated Tally Borders
  • Streamlined Access
  • Ocean-Bound Plastics & Aluminum Build



Overview

Control your PTZ multicamera setup and monitor up to four cameras simultaneously with the BirdDog KBD PTZ Controller with Integrated Screen. Built with ocean-bound plastics and recyclable aircraft-grade aluminum, the KDP boasts a rugged, ergonomic design with a large 1280 x 720 display to allow you to quickly pair and switch cameras with a single keystroke.

The new Effortless Camera Settings Sync function enables you to easily copy settings from one X-series device to another, and the integrated tally borders facilitate live switching with optional TriCaster or vMix platforms. The KDP offers NDI|HX2 and NDI|HX3 support as well as VISCA-IP, ONVIF, RS-232, and RS-422 for smooth workflow versatility. Balancing power, operational comfort, and eco-friendly innovation, the KDP is the ideal companion for studio production, live events, and mobile program acquisition applications.


Key Specs

General
Number of Supported Cameras
255 Channels via IP
Supported Control Protocols
IP
NDI
NDI|HX2
NDI|HX3
ONVIF
Pelco-D
Pelco-P
RS-232
RS-422
VISCA
IP Streaming
NDIHX, ONVIF: UHD 4K
Control I/O
1x D-Sub 9-Pin (RS-232) Input/Output
1x Phoenix (RS-422) Input/Output
1x RJ45 (IP Control, LAN) Input/Output
Other I/O
1x USB-A Input/Output
Controls
1x 3-Axis, Pan/Tilt, Programmable, Multifunction, Auto-Focus, Manual-Focus, Camera Movement Speed, Focus Speed, White Balance Joystick
Focus, Auto-Focus, Manual-Focus, Gain, Camera Selection, Preset Selection, Menu Buttons
Presets
255 via IP, RS-232, VISCA, Pelco-P, Pelco-D
Display
Native Resolution
1280 x 720
Touchscreen
No
Power
PoE Support
PoE 802.3af
Power Connectors
1x Barrel / Coaxial
Power Consumption
≤5 W
Input Power
12 VDC
Physical
Operating Conditions
14 to 130°F / -10 to 54°C at 20 to 80% Humidity
Storage Conditions
14 to 130°F / -10 to 54°C at 0 to 90% Humidity
Security Lock Support
No
Dimensions
14.8 x 7 x 4.6" / 377 x 177 x 118 mm

What is in the Box:

  • BirdDog KBD PTZ Controller with Integrated Screen
  • Limited 1-Year Manufacturer Warranty
