Sound Devices MixPre-10 II 10-Channel / 12-Track Multitrack 32-Bit Field Recorder
1 / 4
Sound Devices MixPre-10 II 10-Channel / 12-Track Multitrack 32-Bit Field Recorder
Key Features
Field Sound Mixing, Videography & VR
32-Bit Recording / 32-Bit USB Streaming
Record up to 192 kHz / Stream to 96 kHz
8 x High-Gain, Low-Noise Mic Preamps
Records 10 Inputs & Stereo Mix
BNC I/O for LTC Timecode or Word Clock
Adjustable Analog Limiters
Polarity, Low-Cut, Delay & Pan Controls
AC & Battery Powering Options
SD Card with Auto-Copy to USB Drives
Overview
For professional videographers, field recordists, podcasters, and Ambisonics enthusiasts who need pristine audio capture of up to eight microphones, the Sound Devices MixPre-10 II multitrack field recorder is an ideal tool. Record up to ten tracks of external sources (eight channels via XLR-1/4" combo jacks and two channels via a 3.5mm mini jack)—as well as a stereo mix—at sample rates and resolutions of up to 192 kHz / 32-bit, all while monitoring audio in headphones. If you choose to use the MixPre-10 II to stream audio, you'll be able to achieve sample rates up to 96 kHz.
The MixPre-10 II offers many upgrades over its predecessor. Chief among these features is the ability to record at 32-bit floating point to an internal SD card. The unit also functions as an audio interface capable of 32-bit floating point streaming over USB to a Mac computer. This makes it nearly impossible for you to clip (distort) audio on the way in. Whether you're recording hot or making use of the unit's astounding 142 dB dynamic range, you'll only be handicapped by the quality of your microphone.
The device sports the same Kashmir preamps as the MixPre-10T with one key difference: an even lower noise floor, at 130 dBV. With line-level XLR and 3.5mm outputs, you can monitor in both headphones and on a compatible line-level device at the same time. Timecode connections are made possible via BNC, HDMI, and 3.5mm connections.
All of this is available in an eight-channel package that can be powered from wall chargers, AA batteries, or Sony L-series batteries. Whether you use the device in an advanced or basic capacity, the MixPre-10 II will suit any intimate, field-based production.
+48 V, Selectable On/Off (Selectable on Individual Inputs)
Phantom Power Current
10 mA per Channel
Plug-In Power
Yes: 3 V
System Connection
1x USB-C (2.0) 1x USB-A (Control, Text Entry, Thumb Drive, 2.0)
Audio Interface Capability
Multi-Track
Wireless
Bluetooth 4.0
Mobile App Compatible
Yes: Android & iOS App Name: Wingman Functionality: Remote Control
Performance
Frequency Response
WAV: 10 Hz to 80 kHz ±0.5 dB (at 192 kHz)
Gain/Trim Range
Mic Inputs: +6 dB to +76 dB Line Inputs: -20 dB to +30 dB Mic/Aux Inputs: +10 dB to +40 dB Line/Aux Inputs: -10 dB to +20 dB Fader: to +20 dB Headphone Outputs: to +20 dB
Max Input Level
Mic Inputs: +14 dBu Line Inputs: +28 dBu Mic/Aux Inputs: -10 dBu Line/Aux Inputs: +10 dBu
8x AA (Included) 2x L Series (Requires Optional Equipment, Hot-Swappable, Not Included)
AC/DC Power Adapter
12 VDC at 3.75 A (Included)
Input Power
100 to 240 VAC, 50 / 60 Hz at 1.5 A
Physical
Included Accessories
No
Mounting Options
1/4"-20 Male (Top) 1/4"-20 Female (Bottom)
Operating Conditions
-4 to 140°F / -20 to 60°C up to 90% Humidity
Storage Conditions
-40 to 185°F / -40 to 85°C
Dimensions
8.1 x 1.4 x 6.9" / 206 x 36 x 175 mm
Weight
32.1 oz / 0.9 kg (without Batteries)
What's in the Box:
Sound Devices MixPre-10 II 10-Channel / 12-Track Multitrack 32-Bit Field Recorder
Sound Devices MX-8AA Battery Sled for MixPre-3 and MixPre-6
Sound Devices XL-WPH3 45W DC Power Supply for Sound Devices Recorders and Mixers
Limited 1-Year Manufacturer Warranty
Key Features
Field Sound Mixing, Videography & VR
32-Bit Recording / 32-Bit USB Streaming
Record up to 192 kHz / Stream to 96 kHz
8 x High-Gain, Low-Noise Mic Preamps
Records 10 Inputs & Stereo Mix
BNC I/O for LTC Timecode or Word Clock
Adjustable Analog Limiters
Polarity, Low-Cut, Delay & Pan Controls
AC & Battery Powering Options
SD Card with Auto-Copy to USB Drives
Overview
For professional videographers, field recordists, podcasters, and Ambisonics enthusiasts who need pristine audio capture of up to eight microphones, the Sound Devices MixPre-10 II multitrack field recorder is an ideal tool. Record up to ten tracks of external sources (eight channels via XLR-1/4" combo jacks and two channels via a 3.5mm mini jack)—as well as a stereo mix—at sample rates and resolutions of up to 192 kHz / 32-bit, all while monitoring audio in headphones. If you choose to use the MixPre-10 II to stream audio, you'll be able to achieve sample rates up to 96 kHz.
The MixPre-10 II offers many upgrades over its predecessor. Chief among these features is the ability to record at 32-bit floating point to an internal SD card. The unit also functions as an audio interface capable of 32-bit floating point streaming over USB to a Mac computer. This makes it nearly impossible for you to clip (distort) audio on the way in. Whether you're recording hot or making use of the unit's astounding 142 dB dynamic range, you'll only be handicapped by the quality of your microphone.
The device sports the same Kashmir preamps as the MixPre-10T with one key difference: an even lower noise floor, at 130 dBV. With line-level XLR and 3.5mm outputs, you can monitor in both headphones and on a compatible line-level device at the same time. Timecode connections are made possible via BNC, HDMI, and 3.5mm connections.
All of this is available in an eight-channel package that can be powered from wall chargers, AA batteries, or Sony L-series batteries. Whether you use the device in an advanced or basic capacity, the MixPre-10 II will suit any intimate, field-based production.
+48 V, Selectable On/Off (Selectable on Individual Inputs)
Phantom Power Current
10 mA per Channel
Plug-In Power
Yes: 3 V
System Connection
1x USB-C (2.0) 1x USB-A (Control, Text Entry, Thumb Drive, 2.0)
Audio Interface Capability
Multi-Track
Wireless
Bluetooth 4.0
Mobile App Compatible
Yes: Android & iOS App Name: Wingman Functionality: Remote Control
Performance
Frequency Response
WAV: 10 Hz to 80 kHz ±0.5 dB (at 192 kHz)
Gain/Trim Range
Mic Inputs: +6 dB to +76 dB Line Inputs: -20 dB to +30 dB Mic/Aux Inputs: +10 dB to +40 dB Line/Aux Inputs: -10 dB to +20 dB Fader: to +20 dB Headphone Outputs: to +20 dB
Max Input Level
Mic Inputs: +14 dBu Line Inputs: +28 dBu Mic/Aux Inputs: -10 dBu Line/Aux Inputs: +10 dBu
8x AA (Included) 2x L Series (Requires Optional Equipment, Hot-Swappable, Not Included)
AC/DC Power Adapter
12 VDC at 3.75 A (Included)
Input Power
100 to 240 VAC, 50 / 60 Hz at 1.5 A
Physical
Included Accessories
No
Mounting Options
1/4"-20 Male (Top) 1/4"-20 Female (Bottom)
Operating Conditions
-4 to 140°F / -20 to 60°C up to 90% Humidity
Storage Conditions
-40 to 185°F / -40 to 85°C
Dimensions
8.1 x 1.4 x 6.9" / 206 x 36 x 175 mm
Weight
32.1 oz / 0.9 kg (without Batteries)
What's in the Box:
Sound Devices MixPre-10 II 10-Channel / 12-Track Multitrack 32-Bit Field Recorder
Sound Devices MX-8AA Battery Sled for MixPre-3 and MixPre-6
Sound Devices XL-WPH3 45W DC Power Supply for Sound Devices Recorders and Mixers
Limited 1-Year Manufacturer Warranty
$686.08
Original: $1,960.24
-65%
Sound Devices MixPre-10 II 10-Channel / 12-Track Multitrack 32-Bit Field Recorder—
$1,960.24
$686.08
