Blackmagic Design Video Assist 7" 12G-SDI/HDMI HDR Recording Monitor
1 / 4
Blackmagic Design Video Assist 7" 12G-SDI/HDMI HDR Recording Monitor
Key Features
7" 1920 x 1200 Touchscreen LCD
Record up to DCI or UHD 4K HDR Video
HDMI and 12G-SDI Video Inputs & Outputs
10-Bit, 4:2:2 ProRes & DNxHD Encoding
Blackmagic Raw with Select Cameras
3D LUTs, 2500 cd/m² Brightness
Stores to Dual SDHC/XC Memory Slots
Two Balanced Mini-XLR Audio Inputs
Histogram, Waveform, Vectorscope
Dual L-Series Battery Slots, AC Adapter
Overview
Add professional monitoring and high-quality recording to virtually any camera with the Blackmagic Design Video Assist 7" 12G-SDI/HDMI HDR Recording Monitor. It features a bright 7", 1920 x 1200 display with 2500 cd/m² brightness to help you frame and focus your shots and provides 12G-SDI and HDMI inputs for recording the video output from professional and consumer cameras. The monitor also features two balanced 3-pin mini-XLR inputs with 48V phantom power support for crisp audio recording. You can monitor and record HDR video up to DCI 4K, UHD 4K, 2K, or HD 10-bit 4:2:2, and up to 16 channels of embedded 24-bit 48 kHz audio. Blackmagic Raw recording is available for select Canon, FUJIFILM, Nikon, Panasonic, and SIGMA cameras.
The Video Assist records using dual high-speed UHS-II SD slots to SDHC/XC memory cards. You can also use the USB-C 3.1 Gen 1 port to record to an external drive, as well as use it for configuring and upgrading the monitor. Video is recorded using industry-standard Apple ProRes (HQ, 422, LT, or Proxy) and Avid DNxHD and DNxHR codecs.
Up to 4096 x 2160 Blackmagic Raw ProRes 422, 422 HQ, LT, Proxy 10-Bit 4:2:2 at up to 60 fps DNxHD HQX, LB, LB MXF, SQ, SQ MXF 10-Bit 4:2:2 at up to 60 fps
Maximum Audio Tracks
16
Phantom Power
+48 V
Power
Input Power
100 to 240 VAC, 50 / 60 Hz 12 VDC
Built-In Battery
No
Battery Type
2x L-Series
Power Consumption
36 W
General
Environmental Resistance
No
Operating Conditions
32 to 72°F / 0 to 40°C up to 90% Humidity
Storage Conditions
-4 to 113°F / -20 to 45°C
Dimensions
7.6 x 5.14 x 1.45" / 19.3 x 13.06 x 3.68 cm
Weight
29.1 oz / 824.99 g
Packaging Info
Package Weight
3.065 lb
Box Dimensions (LxWxH)
10.2 x 9.5 x 3.3"
What's in the Box:
Blackmagic Design Video Assist 7" 12G-SDI/HDMI HDR Recording Monitor
12 VDC, 36W Power Adapter
Limited 1-Year Manufacturer Warranty
