Blackmagic Design HyperDeck Studio 4K Pro

Product image 1
1 / 2

Blackmagic Design HyperDeck Studio 4K Pro

Key Features
  • 1 RU File-Based Video Recorder
  • H.264/H.265 10-Bit 4:2:2 Video
  • Records Compressed in ProRes / DNxHD
  • 1 x 12G-SDI Input, 2 x 12G-SDI Outputs
  • 2 x 2.5" SSD Slots & 2 x SD Card Slots
  • 1 x HDMI Input, 1 HDMI Output
  • 1 x SDI Loop Output, 1 x USB-C Out
  • Speaker, Remote, 10G Ethernet Port
  • Front-Panel Buttons, Jog Wheel, LCD
  • Timecode, Reference & RS-422 In/Out



Overview

The Blackmagic Design HyperDeck Studio 4K Pro is an updated 1 RU file-based deck that features the same functionality and control of professional tape decks in a digital design. This model updates the previous HyperDeck Studio models with several features including 12G-SDI support, two added SD card slots, USB-C recording output, timecode input and output, Ref input and output, a redesigned jog/shuttle wheel, 10G Ethernet, and a speaker on the front.

The Studio 4K Pro records video with 10-bit 4:2:2 color using either ProRes or DNxHD codecs, as well as the H.264 and H.265 compression formats. With two SSD slots and two SD card slots, you can record almost endlessly as one SSD becomes full, recording automatically continues on to the other, and the SD card slots are also hot-swappable. The Studio 4K Pro features one 12G-SDI input, two 12G-SDI outputs, a loop-through 12G-SDI output, a dedicated SDI monitor output, and there's also one HDMI input and one HDMI output that can all output up to DCI 4K. The 4K Pro can even play ProRes 4444 files in true UHD for fill and key outputs. The ports autodetect the signal and will adjust to the SD, HD, 6G-SDI, or 12G-SDI format input. The 3-pin XLR timecode input and output allow you to sync timecode with other devices, and it also allows you to daisy-chain with other devices to create a timecode sync chain.
The Studio 4K Pro is a 1 RU rack-mountable unit, with built-in rack mount ears. It features illuminated front panel button control and a heavy jog/shuttle wheel for analog scrubbing. RS-422 control is supported for external control using the Ref input and output ports. The USB-C port allows you to record to external disks, and you can also use it to plug into a computer to use as a source for a web stream. An integrated LCD on the front panel allows you to monitor the video and display timecode and transport information.



Key Specs

General
Display Size
2.2" LCD
Format Support
DCI/UHD 4K 2160p: 30/29.97/25/24/23.98
2K 1440p: 30/29.97/25/24/23.98
1080p: 60/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

NTSC/PAL
525i 59.94
625i 50
480p60 and 576p50 via HDMI Only
Inputs/Outputs
USB I/O
1 x USB-C 3.1/3.2 Gen 2 Female Output
Video I/O
1x BNC (12G-SDI) Input
2x BNC (12G-SDI) Output
2x BNC (3G-SDI) Loop Output
1x HDMI 2.0 Input
1x HDMI 2.0 Output
Audio I/O
1x 1/4" Headphone Output
Network
1 x RJ45, 10 Gb/s
Supported Operating Systems
macOS 10.15 Catalina
macOS 11.1 Big Sur or Later
Windows 10, 64-Bit
Media Slots
2 x 2.5" SSD
2 x SD Card
Embedded Audio
Input:
16 x Channels SDI
8 x Channels HDMI

Output:
8 x Channels SDI
8 x Channels HDMI
Codecs Supported
ProRes HQ QuickTime
ProRes 422 QuickTime
ProRes LT QuickTime
ProRes Proxy QuickTime for all Formats up to 2160p30
ProRes 4444 QuickTime up to 1080p60 with Auto Routing of Fill and Key over SDI A and B Outputs (Playback Only)

DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD Formats up to 60 fps
DNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p Formats up to 30 fps

H.265 SDI 4:2:2 10-Bit, H.265 High 4:2:0 10-Bit, H.265 Medium 4:2:0 10-Bit, H.265 Low 4:2:0 10-Bit for all 2160p Formats up to 60 fps
H.264 SDI 4:2:2 10-Bit, H.264 High 4:2:0 8-Bit, H.264 Medium 4:2:0 8-Bit, H.264 Low 4:2:0 8-Bit for all Progressive formats up to 1080p60
Color Precision
10-Bit
Color Space
Rec. 601, Rec. 709, Rec. 2020
3D LUTS can be Applied to SDI Monitor Out
Device Control
1 x RS-422 Input
1 x RS-422 Output
HDR Support
Hybrid Log Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084
Multiple Rate Support
Autodetection of SD, HD, 6G-SDI, and 12G-SDI
Rack Size
1 RU
Reference Input
1 x BNC
Reference Output
1 x BNC
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2084, and SMPTE 2108-1
SDI Metadata Support
HD RP188 and closed captioning CEA-708
HDR Metadata Supported on SDI
SSD Interface
2 x 2.5" SATA III 6 Gb/s
Sampling
Video: 4:2:2 YUV
Audio: 24-Bit, 48 kHz
Speaker
Mono
Timecode
1 x XLR (Input)
1 x XLR (Output)
Power
Power Source
AC Input
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
12 VDC
Power Consumption
100 W (Maximum)
Power Input Connection
4-Pin XLR Input
Physical
Operating Conditions
32 to 104°F / 0 to 40°C up to 90% Humidity
Storage Conditions
-4 to 140°F / -20 to 60°C up to 90% Humidity
Dimensions
19 x 9.3 x 1.7" / 48.3 x 23.6 x 4.4 cm
Weight
4.65 lb / 2.11 kg



What's in the Box:

  • Blackmagic Design HyperDeck Studio 4K Pro
  • Limited 1-Year Manufacturer Warranty
