Zoom R12 MultiTrak Portable Recorder and Control Surface

Product image 1
1 / 5

Zoom R12 MultiTrak Portable Recorder and Control Surface

Key Features

  • Multifunctional Production Surface
  • 8-Track Recording: 24-Bit / 44.1 kHz
  • 2.4" Color LCD Touchscreen
  • FX Channel, Compressor, Pan & 3-Band EQ
  • 2 x XLR-1/4" Combo Inputs, Phantom Power
  • USB-C 2x4 Interface, SDXC Record Support
  • Up to 5 Hours on Four AA Batteries
  • 150 Preloaded Drum Loops, Click Track
  • Sequence Play for Backing Tracks
  • Includes USB-C Cable & AC Adapter

Overview

Built for musicians who live to make music, the R12 MultiTrak from Zoom is a comprehensive and highly portable, all-in-one production surface, packing an 8-track, 24-bit / 44.1 kHz digital recorder with 2x4 audio interface capability in a battery powered chassis, allowing you to make music anywhere you are. The R12 wears many hats for the modern musician, featuring control surface functionality, 150 preloaded drum loops, a customizable click track, a dedicated FX channel with four options, a compressor on inputs 1 and 2, pan and 3-band EQ control per track, a tuner, and even a highly musical FM synthesizer, letting you easily record albums, perform live, or produce quality streaming content thanks to features like sequence play for backing tracks.

The R12 sports a large, colorful 2.4" LCD touchscreen with intuitive control functions like swipe editing, two XLR-1/4" TRS combo inputs, with Hi-Z on input 1 and selectable phantom power on both, balanced 1/4" monitor outputs, a 3.5mm output with support for high-powered headphones, and a USB-C terminal for audio interface and bus power duties (cable included). Powering the R12 is as simple as loading in four AA batteries for up to 5 hours of continuous use, and you can also power the unit with the included AD-17 AC adapter, providing three methods of powering your recorder.


Key Specs

General
Form Factor
Desktop
Number of Tracks
WAV:
8 (2 Inputs + Stereo Mix)
Maximum Simultaneous Tracks
2x Recording / 8x Playback (at 44.1 kHz)
Display
1x 2.4" Color LCD Touchscreen (Backlit)
Maximum Sampling Rate
44.1 kHz / 24-Bit
Number of Microphone Inputs
2
Built-In Microphone
No
Input Level Adjustment
2x Knob
Sample Pads
No
Signal Processing
Gain/Trim Range
+6 dB to +50 dB
EQ
Input Channels:
3-Band Shelving (Mono Channels)
EQ Parameters
High: ±12 dB at 10 kHz
Mid: ±12 dB at 2.5 kHz
Low: ±12 dB at 100 Hz
Dynamic Processing
Input Channels:
Compressor, Limiter, Gate
Solo/Mute
Solo, Mute per Input Channel
Built-In Effects
10x Effect (Type Unspecified)
Connectivity
Analog Audio I/O
2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
2x 1/4" TRS Balanced Line Output
1x 1/8" / 3.5 mm TRS Headphone Output
Phantom Power
48 V, Selectable On/Off (Selectable on Individual Inputs)
Digital Audio I/O
No
Host Connection Protocol
USB 2.0
USB (Non-Host)
No
Sync I/O
No
Network I/O
No
MIDI I/O
No
Performance
Frequency Response
20 Hz to 20 kHz +0.5/-1 dB
Maximum Output Level
+1 dBu
Headphone Output Power
1/8" / 3.5 mm:
45 mW per Channel into 32 Ohms
Impedance
Combo XLR-1/4" Mic/Line Inputs:
3.9 Kilohms
1/4" Hi-Z Inputs:
1 Megohm
Metronome
Tempo Range: 40.0 to 250.0 BPM
Time Signatures: 3/4, 4/4, 6/8
Rhythm
Number of Loops: 150
Sound Force Format: PCM
Synth Section
Sound Source Format : FM
Polyphone: 8
Number of Sound Types: 18 (Plus PCM Drum Kit)
Tuner
Chromatic
Guitar
Bass
Open A
Open D
Open E
Open G
DADGAD
Digital Audio
Audio File Formats
Recording:
WAV
Sample Rates
44.1 kHz (Recording to SD Card)
Bit Depths
16 / 24-Bit
Audio Storage & Playback
Supported Media
microSDXC Card
Media/Memory Card Slot
Single Slot: microSD/microSDHC/microSDXC
Supported Media Capacity
1 TB Maximum
Compatibility
OS Compatibility
macOS / Windows
Power
Power Requirements
Battery, USB Bus Power
DC Input Power
5 VDC at 1A (USB Bus Power)
AC/DC Power Adapter
5 VDC at 1 A
Battery Type
4x AA
Approximate Battery Life
5 Hours (AA Alkaline)
5 Hours (AA NiMH)
11 Hours (AA Lithium)
Physical
Dimensions
10.1 x 6.2 x 2.4" / 256 x 158 x 61 mm
Weight
29.2 oz / 827.0 g (with Batteries)
Packaging Info
Package Weight
2.415 lb
Box Dimensions (LxWxH)
12.4 x 7.1 x 2.7"


What's in the Box:

  • Zoom R12 MultiTrak Portable Recorder and Control Surface
  • AD-17 AC Adapter
  • USB-C Cable
  • Limited 1-Year Manufacturer Warranty

Key Features

  • Multifunctional Production Surface
  • 8-Track Recording: 24-Bit / 44.1 kHz
  • 2.4" Color LCD Touchscreen
  • FX Channel, Compressor, Pan & 3-Band EQ
  • 2 x XLR-1/4" Combo Inputs, Phantom Power
  • USB-C 2x4 Interface, SDXC Record Support
  • Up to 5 Hours on Four AA Batteries
  • 150 Preloaded Drum Loops, Click Track
  • Sequence Play for Backing Tracks
  • Includes USB-C Cable & AC Adapter

Overview

Built for musicians who live to make music, the R12 MultiTrak from Zoom is a comprehensive and highly portable, all-in-one production surface, packing an 8-track, 24-bit / 44.1 kHz digital recorder with 2x4 audio interface capability in a battery powered chassis, allowing you to make music anywhere you are. The R12 wears many hats for the modern musician, featuring control surface functionality, 150 preloaded drum loops, a customizable click track, a dedicated FX channel with four options, a compressor on inputs 1 and 2, pan and 3-band EQ control per track, a tuner, and even a highly musical FM synthesizer, letting you easily record albums, perform live, or produce quality streaming content thanks to features like sequence play for backing tracks.

The R12 sports a large, colorful 2.4" LCD touchscreen with intuitive control functions like swipe editing, two XLR-1/4" TRS combo inputs, with Hi-Z on input 1 and selectable phantom power on both, balanced 1/4" monitor outputs, a 3.5mm output with support for high-powered headphones, and a USB-C terminal for audio interface and bus power duties (cable included). Powering the R12 is as simple as loading in four AA batteries for up to 5 hours of continuous use, and you can also power the unit with the included AD-17 AC adapter, providing three methods of powering your recorder.


Key Specs

General
Form Factor
Desktop
Number of Tracks
WAV:
8 (2 Inputs + Stereo Mix)
Maximum Simultaneous Tracks
2x Recording / 8x Playback (at 44.1 kHz)
Display
1x 2.4" Color LCD Touchscreen (Backlit)
Maximum Sampling Rate
44.1 kHz / 24-Bit
Number of Microphone Inputs
2
Built-In Microphone
No
Input Level Adjustment
2x Knob
Sample Pads
No
Signal Processing
Gain/Trim Range
+6 dB to +50 dB
EQ
Input Channels:
3-Band Shelving (Mono Channels)
EQ Parameters
High: ±12 dB at 10 kHz
Mid: ±12 dB at 2.5 kHz
Low: ±12 dB at 100 Hz
Dynamic Processing
Input Channels:
Compressor, Limiter, Gate
Solo/Mute
Solo, Mute per Input Channel
Built-In Effects
10x Effect (Type Unspecified)
Connectivity
Analog Audio I/O
2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
2x 1/4" TRS Balanced Line Output
1x 1/8" / 3.5 mm TRS Headphone Output
Phantom Power
48 V, Selectable On/Off (Selectable on Individual Inputs)
Digital Audio I/O
No
Host Connection Protocol
USB 2.0
USB (Non-Host)
No
Sync I/O
No
Network I/O
No
MIDI I/O
No
Performance
Frequency Response
20 Hz to 20 kHz +0.5/-1 dB
Maximum Output Level
+1 dBu
Headphone Output Power
1/8" / 3.5 mm:
45 mW per Channel into 32 Ohms
Impedance
Combo XLR-1/4" Mic/Line Inputs:
3.9 Kilohms
1/4" Hi-Z Inputs:
1 Megohm
Metronome
Tempo Range: 40.0 to 250.0 BPM
Time Signatures: 3/4, 4/4, 6/8
Rhythm
Number of Loops: 150
Sound Force Format: PCM
Synth Section
Sound Source Format : FM
Polyphone: 8
Number of Sound Types: 18 (Plus PCM Drum Kit)
Tuner
Chromatic
Guitar
Bass
Open A
Open D
Open E
Open G
DADGAD
Digital Audio
Audio File Formats
Recording:
WAV
Sample Rates
44.1 kHz (Recording to SD Card)
Bit Depths
16 / 24-Bit
Audio Storage & Playback
Supported Media
microSDXC Card
Media/Memory Card Slot
Single Slot: microSD/microSDHC/microSDXC
Supported Media Capacity
1 TB Maximum
Compatibility
OS Compatibility
macOS / Windows
Power
Power Requirements
Battery, USB Bus Power
DC Input Power
5 VDC at 1A (USB Bus Power)
AC/DC Power Adapter
5 VDC at 1 A
Battery Type
4x AA
Approximate Battery Life
5 Hours (AA Alkaline)
5 Hours (AA NiMH)
11 Hours (AA Lithium)
Physical
Dimensions
10.1 x 6.2 x 2.4" / 256 x 158 x 61 mm
Weight
29.2 oz / 827.0 g (with Batteries)
Packaging Info
Package Weight
2.415 lb
Box Dimensions (LxWxH)
12.4 x 7.1 x 2.7"


What's in the Box:

  • Zoom R12 MultiTrak Portable Recorder and Control Surface
  • AD-17 AC Adapter
  • USB-C Cable
  • Limited 1-Year Manufacturer Warranty
$93.30

Original: $266.58

-65%
Zoom R12 MultiTrak Portable Recorder and Control Surface

$266.58

$93.30
