Key Features

• 5" 1920 x 1080 Touchscreen Display
• 2000 cd/m², 10-Bit LCD Panel, DCI P3
• 2-Pin Locking Power Input
• 5-Pin Locking USB for RED Camera Control

Overview

Monitor your camera with the CINE 5 Touchscreen On-Camera Monitor from SmallHD. Featuring a sharp 5" display suitable for indoor or outdoor use, the CINE 5 monitor supports various HD and SD formats via one full-size HDMI input, one HDMI output, one 3G-SDI input, and one 3G-SDI selectable input/output. The monitor also supports cross conversion from HDMI to SDI and from SDI to HDMI.

Key Specs

Display Size	5.0" / 12.7 cm
Native Resolution	1920 x 1080
Touchscreen	Yes
HDR Support	No
Video I/O	1x HDMI 2.0 Input 1x HDMI 2.0 Loop Output 1x BNC (3G-SDI) Input 1x BNC (3G-SDI) Loop Output
Media/Memory Card Slot	No
Video Format	HDMI (8/10/12/16-Bit 4:4:4/4:2:2 YCC) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 120/119.88/100/60/59.94/50 720p: 120/119.88/100/60/59.94/50/30/29.97/25/24/23.98 576p: 200/100/50 480p: 240/239.76/120/119.88/100/60/59.94 480i: 240/239.76/120/119.88/100/60/59.94 576i: 200/100/50 SDI (10-Bit 4:2:2 YCC) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 120/119.88/100/60/59.94/50 720p: 60/59.94/50/30/29.97/25/24/23.98 576i: 50 480i: 59.94
Mounting	6x Anti-Twist 1/4"-20 Female 4x M3 Female
