Shure BLX14/SM31 Wireless Cardioid Fitness Headset Microphone System

Product image 1
1 / 5

Shure BLX14/SM31 Wireless Cardioid Fitness Headset Microphone System

Key Features

  • For Fitness Instructors
  • SM31FH Cardioid Fitness Headset Mic
  • Moisture-Repellent Mic Construction
  • Lightweight Bodypack Transmitter
  • Single-Channel Tabletop Receiver
  • 123 Auto-Scan Frequencies
  • Internal Antenna Diversity
  • 14-Hr AA Batteries
  • Expandable to 12 Mic Channels/300' Range



Overview

The Shure BLX14/SM31 brings fitness and aerobics instructors a cost-effective wireless headset microphone system with quality sound, simple setup, intuitive operation, and dependable performance right out of the box. It includes the compact and lightweight BLX4 single-channel tabletop receiver with internal antennas, ideal for portable use.

The BLX14/SM31 also includes an SM31FH cardioid fitness headset mic with windscreen and a bodypack transmitter. The headset is specifically designed to stay comfortable and securely in place, even during the most active workouts. Moisture-repellent hydrophobic fabric helps protect the microphone capsule from sweat and humidity.

The receiver features one-touch QuickScan frequency selection to quickly search 123 available frequencies and locate a clean RF channel in case of interference. The system provides up to 14 hours of continuous use with two AA batteries, at a range up to 300'. Up to 12 mic channels can operate simultaneously in each frequency band.

Key Specs

Wireless Technology
Analog UHF
Included Transmitters
1x Bodypack
Diversity
Antenna Diversity
Max Operating Range
300' / 91.4 m (Line of Sight)
Receiver Type
Tabletop
Microphone Type
Headset
Polar Pattern
Cardioid

System
Wireless Technology
Analog UHF
Number of RF Channel Frequencies
123
Included Transmitters
1x Bodypack
Diversity
Antenna Diversity

RF Bandwidth
24 MHz
RF Channel Scanning
Auto-Scan
Max Operating Range
300' / 91.4 m (Line of Sight)
Max Transmitters per Band
12
Built-In Recorder
No
Timecode Support
No
Mobile App Compatible
No
Dynamic Range
100 dBA

Receiver
Receiver Type
Tabletop
Antenna
2x Internal, Fixed
Number of Audio Channels
1
Built-In Microphone
No
Audio I/O
1x XLR 3-Pin Male Balanced Output
1x 1/4" TS Female Unbalanced Output
Audio Output Level
XLR Output:
-27 dBV (Mic Level)
1/4" Output:
-13 dBV (Instrument Level)
Frequency Response
50 Hz to 15 kHz (Dependent on Mic)
USB Class-Compliant
No USB Connectivity
Impedance
XLR Output:
200 Ohms
1/4" Output:
50 Ohms
Power Requirements
AC/DC Power Adapter
AC/DC Power Adapter
12 to 15 VDC at 160 mA, Center-Positive (Included)
Input Power
100 to 240 VAC, 50 / 60 Hz at 150 mA
Display & Indicators
1x Multi-Segment LED (Channel, Group)
2x LED (AF Level, Sync)
Housing
ABS
Dimensions
7.4 x 1.6 x 4.1" / 188 x 40 x 103 mm
Weight
8.5 oz / 241 g

Transmitter
Transmitter Type
Bodypack
RF Output Power
10 mW
Built-In Microphone
No
Audio I/O
1x TA4/Mini-XLR 4-Pin Male Input (Locking)
Muting
Off/On Switch
Auto-Level Control
No
Gain Range
-16 to +10 dB
Sync Method
Manual
Antenna
1x Flexible Whip, Fixed (Beltpack)
Power Requirements
Battery
Battery Type
2x AA (Included)
Approx. Battery Life
14 Hours (Alkaline)
Display & Indicators
1x Multi-Segment LED (Channel, Group)
1x LED (Battery Status, Power)
Housing
ABS
Dimensions
2.5 x 4.3 x 0.8" / 64 x 110 x 21 mm
Weight
2.6 oz / 75 g (without Batteries)

Microphone
Microphone Type
Headset
Color
Black
Sound Field
Mono
Capsule
Electret Condenser
Polar Pattern
Cardioid
Frequency Range
45 Hz to 20 kHz
SNR
66 dB
Maximum SPL
145 dB SPL
Impedance
600 Ohms
Dynamic Range
117 dB
Output Connector
1x TA4F/Mini-XLR 4-Pin Female (Locking)
Cable Length
3.61' / 1.1 m
Operating Voltage
5 V
Weight
2.12 oz / 60 g

Packaging Info
Package Weight
4.15 lb
Box Dimensions (LxWxH)
13.55 x 11.8 x 4.25"

What's in the Box:
  • Shure BLX14/SM31 Wireless Cardioid Fitness Headset Microphone System
  • Shure BLX4 Tabletop Wireless Receiver
  • Shure BLX1 Wireless Bodypack Transmitter
  • Shure SM31FH Fitness Headset Condenser Microphone
    Windscreen
  • Shure PS24US Power Supply for Select Wireless Receivers
  • 2 x AA Batteries
  • Limited 1-Year Manufacturer Warranty
