- For Live Sound Reinforcement & Playback
- 12" Woofer, 1.35" Compression Driver
- 550W Bi-Amplified Class-D Power
- Integrated Sound Processor
- XLR and 1/4" TRS Input with 2-Band EQ
- Wide Dispersion, Large Exponential Horn
- Link Output for Adding Speakers
- Trapezoidal Shape with 35mm Pole Socket
- Handles for Easy Carry and Setup
- Designed and Engineered in Germany
Overview
Provide yourself with a versatile live sound reinforcement solution with the B212D from Behringer, a powerful, bi-amped, 550W active PA system with one 12" long-excursion driver and one 1.35" compression driver. With a 2-band EQ and an internal DSP for a clean signal, the B212D offers exceptional value.
Key Specs
| Configuration |
Active 2-Way
|
| Enclosure Type |
Bass-Reflex Floor Monitor
|
| Total Power Capacity |
Bi-Amp:
550 W
|
| HF Driver |
1 x 1.35" / 3.43 cm Aluminum Compression Driver
|
| MF Driver |
No
|
| LF Driver |
1x 12" / 30.5 cm Woofer
|
| Wireless Connectivity |
No
|
| Color |
Black
|
| Enclosure Type |
Bass-Reflex Floor Monitor
|
| Total Power Capacity |
Bi-Amp:
550 W
|
| Amplifier Power Rating |
LF:
1 x 280 W RMS (at 8 Ohms)
1 x 450 W Peak (at 8 Ohms)
HF:
1 x 65 W RMS (at 8 Ohms)
1 x 100 W Peak (at 8 Ohms)
|
| Amplifier Class |
Class-D
|
Drivers
| HF Driver |
1 x 1.35" / 3.43 cm Aluminum Compression Driver
|
| MF Driver |
No
|
| LF Driver |
1x 12" / 30.5 cm Woofer
|
Performance
| Frequency Response |
65 Hz to 20 kHz
|
| Maximum SPL |
125 dB SPL
|
| Max Input Level |
+22 dBu
|
| Gain Range |
Up to 30 dB
|
| I/O Impedance |
Input:
20 Kilohms
|
| Protections |
Signal Limiter
|
Connectivity
| Audio I/O |
1x XLR 3-Pin Female Balanced Mic Input (Lockable)
1x 1/4" TRS Female Balanced Line Input
1x XLR 3-Pin Male Balanced Link Output (Lockable)
|
| Network I/O |
No
|
| USB I/O |
No
|
| Wireless Connectivity |
No
|
| Bluetooth |
No
|
| Mobile App Compatible |
No
|
Signal Processing
| Crossover |
2.4 kHz
|
| EQ |
1x HF Shelf:
±15 dB at 12 kHz (on Master)
±15 dB at 80 Hz (on Master)
|
| Parametric EQ |
No
|
| Semi-Parametric EQ |
No
|
| Filters |
No
|
| Dynamic Processing |
Optical Limiter
|
| Alignment Delay |
No
|
| Phase Adjustment |
No
|
Power
| AC Input Power |
Factory Selectable:
120 VAC, 60 Hz (T 6.3 A H 250 V)
|
| AC Power I/O |
1x IEC Input
|
| Power Consumption |
600 W (Max)
|
Physical
| Color |
Black
|
| Mounting |
1 x 1.4" / 35 mm Pole Socket
|
| Handles |
1x Top
|
| Environmental Resistance |
No
|
| Dimensions |
21.7 to 13.6 x 10.6" / 55.1 to 34.5 x 26.9 cm
|
| Weight |
31.9 lb / 14.5 kg
|
Packaging Info
| Package Weight |
35.3 lb
|
| Box Dimensions (LxWxH) |
24.4 x 16.4 x 12.6"
|
What's in the Box:
- Behringer Eurolive B212D Active 2-Way 550W 12" PA Speaker System
-
Limited 1-Year Manufacturer Warranty
